Wharfedale Diamond 12 3D Dolby Enable Speaker Walnut

Since 1982, Wharfedale’s famous DIAMOND speakers have served as the classic entry point to true high-fidelity sound, their exceptional sonic value for money earning numerous ‘product of the year’ accolades in the UK and around the world. This autumn, with the introduction of the all-new DIAMOND 12 Series, Wharfedale once again raises the bar for affordable, high-performance loudspeakers.

With this newest addition to the record-breaking, award-winning DIAMOND 12 series, Wharfedale takes surround sound to the next level with the DIAMOND 12 3D surround speaker.

Covering the audience in a dome of sound, following Wharfedale’s long history in cinematic and home theatre solutions, you can now have a 3D cinema-audio listening experience at home with your DIAMOND 12 series configuration.
General Description 2-way vertical channel speaker
Design Philosophy and Core Technology
Enclosure Type closed-box system
Transducer Complement 2-way
ABR
Bass Driver 4"(100mm) advanced PP Cone
Midrange Driver
Treble Driver 1"(25mm) Textile Dome
Full-range Driver
AV Shield No
Sensitivity (2.83V @ 1m) 85dB
Recommended Amplifier Power 20-100W
Peak Power Handling
Peak SPL 95dB
Nominal Impedance 8Ω Compatible
Minimum Impedance 4.3Ω
Frequency Response (+/-3dB) 110Hz ~ 20kHz
Bass Extension (-6dB) 90Hz
Crossover Frequency 3kHz
Cabinet Volume (in litres) 2.7L
Dimensions (mm)
Height (with grille) 145mm
Width 180mm
Depth (with terminals) 310mm
Carton Size 380 x 315 x 255mm
Net Weight 3.2kg/pcs
Gross Weight 7.2kg/ctn
